A light oil coating on the metal part is fine to use with ZERUST®/EXCOR® VCI bags and film. A heavy oil coating may affect the performance of the VCI bag by keeping the vapor corrosion inhibiting molecules from reaching the metal surface. Please contact ZERUST®/EXCOR® to determine the suitability of the oil and application.
ZERUST® ICT®510-C Ferrous VCI Film
ZERUST®/EXCOR® ICT®510-C Ferrous VCI Film provides cost-effective and versatile protection against corrosion damage for ferrous metals in shipping and storage. It is available in various sized rolls, sheets, tubing, and bags.
Features
- Effective corrosion protection and packaging combined in one step
- Metals are ready for use and assembly directly out of the packaging
- Available in many different formulations and sizes
- Provides safe and effective ZERUST® VCI protection
- Recyclable
Product Description
Product Description
ZERUST® ICT®510-C Ferrous VCI film diffuses proprietary ZERUST® VCIs (Vapor Corrosion Inhibitors) to protect ferrous metals from rust and corrosion. Use ZERUST® ICT®510-C Ferrous VCI film to protect metal components and assemblies, machined and cast parts, and more for years‡. For additional protection and use in challenging environments, packaging can be used with ZERUST® corrosion inhibitor liquid RPs and VCI diffuser products. Check with your ZERUST®/EXCOR® representative for a comprehensive corrosion management solution most effective for your metal assets.
ZERUST® is the inventor of poly Vapor Corrosion Inhibitor Technology (VCI), and ZERUST® VCI film has proven its performance and safety with thousands of customers worldwide for nearly 50 years. It is used to protect valuable metal items for manufacturers in industries such as automotive, agricultural, aerospace, and mining. ZERUST®/EXCOR® offers on-site support and service in more than 70 countries via a network of 21 joint venture partnerships.
Videos
Resources
Availability
Availability
ZERUST®/EXCOR® ICT®510-C VCI Ferrous Film is available in many stock and custom options, such as UV and anti-static additives. Contact a ZERUST® account manager for pricing and availability.
Size Range (width):
Bags & Tubing:
2” – 125” (flat)
2” – 150” (gusset)
Sheeting: 2” – 26’
| Part Number | Dimensions and Thickness | Film Type | Film Color and Protection | |
|---|---|---|---|---|
| 100-F-00002 | 36" x 500' x 4 MIL | Sheeting | Ferrous Yellow | |
| 100-F-00064 | 72" x 500' x 4 MIL | Sheeting | Ferrous Yellow | |
| 100-F-00081 | 12' x 250' x 4 MIL | Sheeting | Ferrous Yellow |
FAQs
Frequently Asked Questions
Can VCI bags be used with oil coatings?
Can VCI bags be reused?
Are VCI packaging products made of recycled materials?
Are there any inhalation or contact risks with VCI products?
Can VCI film be recycled?
Does the management of your VCI products meet an ISO Standard?
How do VCI bags work?
How do I know what VCI products to use for my type of metal?
How do I know that I am measuring length, width, and height correctly?
